Sci-Print VX2

Product Description

The Sci-Print VX2 (model #1044) is a fully automated tube labeling system, capable of printing and applying labels to tubes ranging from 0.5 mL to 50 mL in size.

The Sci-Print VX2 can be configured to sort racked tubes, receive bulk tubes, uncap/recap, fill and/or scan barcodes.

Categories: Agricultural Science, Animal Health, Biobanking, Clinical, Drug Discovery, Forensics, Pharmaceutical, Plant & Food Testing, Tube Handling, Tube Labeling, Tube Sorting, Uncapping & Recapping

Download the Product Sheet

Request Product Information

Name*
First Last
Company*
Email*
Address Location*
State*
State
Province*
Province
Region*
Region
Message*
CAPTCHA
Name
This field is for validation purposes and should be left unchanged.

“The Scinomix VX2 is a versatile and easy to use tube labeler. It can handle almost any tube type with the use of swappable heads(now with a universal head which makes it even easier). They can make tube racks for almost any tube type. They offer a variety of various labels depending on your needs, and the software is easy to use. The system itself is reliable as long as it is maintained properly.”

-Wali Malik , GSK

“Eases the burden of storing bulk preparations. Gone are the days of time consuming hand written tube labels that inevitably become illegible. Easy to use. Consistent performance. Captures all relevant reagent information on an easy to read label affixed automatically while you are preparing the reagent. A real time saver.”

-Jim Dalton , Alexion

“We downsized the number of people working in our area but the workload was the same, with the Scinomix we were able to label, fill and sort tubes faster than before, more accurately and with fewer people. We have come to depend on the instrument so much we have purchased another as if it goes down, it would be hard to keep up with the production levels that we currently have.”

-Diane Holder , USDA APHIS

“The VX2 does a wonderful and consistent job of placing labels on the tubes. There is very little upkeep with the maintenance. The results of the labels printed are high quality with reproducible results. I rated this the highest for instrument automation do to the fact of how solid the instrument is without any down time. The service/sales team are very knowledgeable and very kind individuals there, always a pleasure to speak with them over the phone if I ever contact them.”

-David Freedom , Gift of Hope

“We label thousands of tubes every single day and without this labeler, our lab would not be able to fulfill the stringent requirements of our clients. This instrument GETS THE JOB DONE. When there is an issue or mechanical fault, Scinomix has the talented field staff to get it operational immediately.”

-Chris Piccirillo , Rutgers University

“We purchased this machine to alleviate the repetitive motion injuries we were seeing when we aliquoted, capped and labeled over 200,000 tubes per year. It has been very reliable and the support has been immediate when we call for help. Very few problems have been seen and most have been solved with just a call. We have been very satisfied with the use of the Sci-Print VX2 and continue to use it continuously every day.”

-Robert Larson , Salimetrics, LLC

“We use the instrument to label 2D barcoded tubes. The software is super easy to use and configure. It is also very reliable and easy to troubleshoot if something should go wrong (which is very rare). We have been able to write many templates for labeling different types of racks and tube heights. The customer service is also excellent. We have had rapid response from Scinomix and they are always very helpful. We have also started to use it for other applications because it is so easy to use and configure.”

-Karen Wong , Sanofi

“Our lab had a throughput of more than 30,000 tubes in four months and the printer did not have a single breakdown during this period. The service during installation and routine work is outstanding. The software leaves a lot of freedom for genuine processes. Once you have adapted it to your workflow this product is of great value.”

-Mario Richter , AbbVie

“After a thorough evaluation of tube labellers, we chose scinomix. their device met all of our requirements. we have automated tube labelling in two major areas within our laboratory, resulting in major time and cost savings.”

-Tyler Aldredge , Genzyme Genetics

“We use the instrument for labeling tubes and rearraying. It is very effective and we have had very few issues with it. It’s a great instrument.”

-Amanda Embree , Broad Institute

The Sci-Print VX2 is a fully automated tube handling system that offers configurable solutions to each customer. The Sci-Print VX2 caters to a wide range of applications and provides full solutions for a variety of industries.

The Sci-Print VX2 can handle a wide variety of tubes and vials ranging from 0.5 mL to 50 mL in size. In addition to labeling, the Sci-Print VX2 has optional features that can be added to best fit your specific requirements.

We also offer a variety of label kits to accommodate your specific tube application. The label and ribbon combinations have been tested extensively with the Scinomix line of automated labelers. They have proven to be the best fit for ensuring optimal labeling performance.

Features

Throughput of 400 tubes/ hour
6-position work deck (accommodates up to 600 tubes)
Thermal transfer printer
Ability to handle honeycomb plates
Compatible with tubes and vials ranging from 0.5 mL to 15 mL
Options: Filling of aqueous solutions, uncapping and recapping of screw-top lids, 2D barcode scanner used to read or validate
Upgrade to the new patent-pending Universal Gripper

Benefits

Increases productivity and efficiency in the lab
Provides valuable walk away time to attend to other important tasks in the lab
Provides consistency of label placement on each tube
Improves barcode scanning process
Handles multiple tube types with the same system
Eliminates human error that can occur from hand labeling
Reduces repetitive injuries from hand labeling

Enabled Symbologies

These are the current symbologies that we implement.

Code 128
Code 39 (full ASCII)
Interleaved 2 of 5
Data Matrix (2D)

Share With Your Colleagues

Specifications

PC Requirements: Windows PC; HD display; Ethernet port

Power Requirements: 110-240 VAC 50/60 Hz 80W (Max)

Air Requirements: 80-120 PSI @ 1 CFM. The air supply must be oil/contaminant free, with an inline regulator and air dryer.

Environment: Indoor lab (please contact your Account Manager for specific information)

Weight: 90lbs (41kg)

Capacity: 27” (670mm) x 14” (355mm) (LxW)

Max Throughput: 400 tubes per hour (throughput is impacted based on configuration).

Tube Specifications: Volume Range: 0.5 mL to 50 mL, Max Height: 125 mm, Max Diameter: 18 mm

Rack Capacity: 6 position work deck *

Certifications: CE, FCC

Accessories

FAQs

How do I adjust gripper air pressure on the Sci-Print VX2?

The small knob that controls gripper air pressure is located on the underside of the upper gantry (see image).

Note: If you have a new VX2, the knob may look slightly different

It is important to make sure the gripper air pressure is not too high and not too low. If you find that the gripper is not picking up the tube, this could mean your air pressure is too low, so you may need to adjust it to make it stronger. If the gripper air pressure is too strong, this could result in the grippers closing too tight, and the tube breaking

To adjust gripper air pressure:

1.)    Unscrew the lock collar completely by turning it to the left (lock collar is located on the gripper air pressure knob.)

2.)    Once the lock collar is undone, you will be able to adjust the knob to control the air pressure

3.)    To increase air pressure, tighten the knob, or turn right

4.)    To decrease air pressure, loosen the knob, or turn left

What is the Roller Close air pressure?

The Roller Close Pressure Adjust is located on the left side of the machine just behind the roller block assembly.

This air pressure controls how tight the rollers clamp together to label the tube. It is also very important to make sure that the air pressure is not too high and not too low. This air pressure should be adjusted fairly often depending on the size of tube you are using. If you have a smaller tube, the air pressure should be fairly low. If you have a larger tube, the air pressure should be adjusted higher.

How do I adjust VX2 grippers for honeycomb plates?

1.) Unscrew the gripper head from the Z-axis arm

2.) Turn the dowel pin counterclockwise, one quarter to the right

3.) Screw back together in this position using an Allen Wrench

How do I create a new label?

1. Go to the Configuration Menu in the user program

2. Under the configuration menu, select “Label Stock”

The Label Stock Configuration screen will display

– Label stock lets you control the measurements of your label

3. Under the configuration menu, click “Label document”

The Label Document Configuration screen will display

This is essentially the label designer, which will allow you to add all necessary information to your label including text, barcode or an image

How do I measure label stock?

1.) Under the configuration menu, select “Label Stock”

The Label Stock Configuration screen will display

This screen allows the user to define the physical characteristics of the label being used, including the length of the label, the width of the label, and the span of the label.

Here are some clear definitions:

Total Length= measure from the clear space at the beginning of the label to the end of the label

Printable Length = measure just the white part of the label

Width = measure the label vertically

Span= measure the length from the end of the clear tip of the previous label to the tip of the next label, including the clear space (should be about 3mm longer than total length)

How do I change the roller and clamp roller block?

1.) Turn off the air so that the roller assembly can be pulled out of the machine

2.) Remove the screw in the center of the roller using an Allen wrench and lift off the roller

3.) Place the new roller on the spindle and align the slot in the underside with the flats on the spindle

4.) Place a screw into the hole in the center of the roller and gently tighten. Ensure the screw length is approximately 5 mm longer than the depth of the hole.

5.) To swap out the clamp roller or to adjust its height, first remove it by unscrewing the single screw holding it in place.

6.) Remove or ad spacers as necessary so as to position the top of the clamp roller block level with the top of the roller.

7.) Place the roller block onto the actuator base. Insert the screw and gently tighten. Make sure the screw length is approximately 5 mm longer than the depth of the hole.

How do I change VX2 grippers?

1.) Before removing the gripper fingers, press the “e-stop” button and move the arm to a good accessible position.

2.) Reset the “e-stop” while holding the arm at the desired position

3.) Using a flat-ended Allen Wrench, remove each of the screws that hold the grippers onto the gripper actuator. If the head of the screw looks worn, replace it.

4.) To reinstall the grippers, simply reverse this process. Do not over tighten the screws or they may strip, or the heads may become rounded. Depending upon the type of gripper being fitted, different holes and screw sizes may be used.

Can the Sci-Print VX2 label in a cold environment?

Yes. We use Computype TS818 labels that can withstand cold temperatures as low as -196 degrees and as hot as 120 degrees.

Can the Sci-Print VX2 fill tubes?

Yes. Not only can the Sci-Print VX2 label, uncap and cap tubes, but it can also fill tubes by easily attaching a peristaltic pump to the system. The tubes are labeled and filled at the same time and placed back into the rack.

How do I Load Labels for Sci-Print VX2 and Sci-Print Solo?

1.) Load the labels, making sure that you hold the roll together as you position it over the spindle. Make sure the print head is open by turning the green knob 90 degrees counterclockwise.

2.) Feed the labels through the print head, making sure they are positioned under the red adjustable guide and through the red gap sensor.

3.) Thread the labels behind the peel plate, making sure they go behind the roller, not between the roller and the blow tube.

4.) Insert the label liner behind one of the retaining pegs on the take up reel. Turn the take up reel counterclockwise to wind the labels through the system.

5.) Wind the green knob on the spindle counterclockwise to expand the spindle (this helps release the use labels from the spindle the next time they need to be changed).

6.) After winding a few labels through the printer, making sure they move freely, close the pinch roller at the front of the machine, and then close the head.

7.) To thread the labels through the tensioner, push back on the rear most roller to open a gap between the two rollers and drop the labels into the gap.

How do i adjust the Roller Close air pressure?

1.) Unscrew the lock collar completely by turning it to the left

2.) Once the lock collar is undone, you will be able to adjust the knob to control the roller close air pressure

1.) To increase air pressure, tighten the knob, or turn right

2.) To decrease air pressure, loosen the knob, or turn left

3.) If you find the tube breaking or stalling in the labeling process, this could mean the air pressure is adjusted too high
